28 Inch Ball Valve, A105, API 6D, Class 600, RF, Gearbox

China 28 Inch Ball Valve Supplier MED Offers 28 Inch Ball Valve, LF2 Body Material, API 6D Standard, Class 600, RF End Connection, Gearbox Operation
OnLine Service
QQ Skype Online PDF Download
Trunnion Mounted Ball Valve, 8 Inch, 600#, RF 16 Inch Ball Valve, LF2, API 6D, Class 900, RF, Gearbox
Description
China 28Inch Ball Valve Supplier MED Offers 28 Inch Ball Valve, A105 Body Material, API 6D Standard, Class 600, RF End Connection, Gearbox Operation.


Valve Description:
Design Standard: API 6D.
Body Material: A105
Nominal Diameter: 28".
Pressure: CL600.
End Connection: RF.
Face to Face: ASME B16.10.
Working Temperature: -46℃~+200℃.
Mode of Operation: Gearbox.
Test and Inspection: API 598.

Product Range:
Body Material: Carbon Steel, Stainless Steel, Alloy Steel.
Normal Diameter: 2"~60" (DN50~DN1500).
End Connection: BW, Flanged.
Pressure Range: 150lbs~2500lbs(PN16~PN420).
Operation: Lever, Gearbox, Electric, Pneumatic, Electro Hydraulic Actuator, Gas Over Oil Actuator.
Working Temperature: -46℃~+200℃.
